NOV 217Q-4 (Wheatley HP200)
NOV 217Q-4 (Wheatley HP200)
The NOV 217Q-4 (Wheatley HP200) product line is one of our continuous and intermittent-duty reciprocating pump lines. With plunger sizes ranging from 1.250” to 3.375”. The maximum displacement pressure for the NOV 217Q-4 (Wheatley HP200) is between 984 psi (6782 kPA) and 6000 psi (41369 kPA) depending on plunger size.
The NOV 217Q-4 (Wheatley HP200) products will pump up to 339.8 GPM, or 11,652 BPD at peak performance. The NOV 217Q-4 (Wheatley HP200) operates in low-to-high pressure applications and offers 24/7 continuous duty run time, resulting in reduced downtime and savings for your overall operational costs. The NOV 217Q-4 (Wheatley HP200) works in a variety of fluids and offers a variety of fluid end metallurgies.
Recommended Application Types
- Fresh Water
- Salt Water
- Crude Oil
- Natrual Gas
- Propane
- TEG / Glycol
- Butane
- Condensate
PUMP | English Units | 100 RPM | 150 RPM | 200 RPM | 250 RPM | 300 RPM | 390 RPM | ||||||||||
Plunger Dia. In. | Plunger Area Sq. In. | BPD per RPM | GPM per RPM | Max. Press. PSI | BPD | GPM | BPD | GPM | BPD | GPM | BPD | GPM | BPD | GPM | BPD | GPM | |
217Q-4L (HP200AL) | 3.375 | 8.9462 | 29.8759 | 0.8714 | 984 | 2988 | 87.1 | 4482 | 130.7 | 5976 | 174.3 | 7469 | 217.8 | 8963 | 261.4 | 11652 | 339.8 |
3.25 | 8.2958 | 27.7038 | 0.808 | 1061 | 2771 | 80.8 | 4156 | 121.2 | 5541 | 161.6 | 6926 | 202 | 8312 | 242.4 | 10805 | 315.1 | |
3.125 | 7.6699 | 25.6137 | 0.7471 | 1147 | 2562 | 74.7 | 3843 | 112.1 | 5123 | 149.4 | 6404 | 186.8 | 7685 | 224.1 | 9990 | 291.4 | |
3.000 | 7.0686 | 23.6056 | 0.6885 | 1245 | 2361 | 68.8 | 3541 | 103.3 | 4722 | 137.7 | 5902 | 172.1 | 7082 | 206.5 | 9207 | 268.5 | |
2.875 | 6.4918 | 21.6795 | 0.6323 | 1356 | 2168 | 63.2 | 3252 | 94.8 | 4336 | 126.5 | 5420 | 158.1 | 6504 | 189.7 | 8455 | 246.6 | |
2.750 | 5.9396 | 19.8353 | 0.5785 | 1440 | 1984 | 57.9 | 2976 | 86.8 | 3968 | 115.7 | 4959 | 144.6 | 5951 | 173.6 | 7736 | 225.6 | |
2.625 | 5.4119 | 18.0731 | 0.5271 | 1440 | 1808 | 52.7 | 2711 | 79.1 | 3615 | 105.4 | 4519 | 131.8 | 5422 | 158.1 | 7049 | 205.6 | |
217Q-4M (HP200AM) | 2.500 | 4.9087 | 16.3928 | 0.4781 | 1793 | 1640 | 47.8 | 2459 | 71.7 | 3279 | 95.6 | 4099 | 119.5 | 4918 | 143.4 | 6394 | 186.5 |
2.375 | 4.4301 | 14.7945 | 0.4315 | 1986 | 1480 | 43.2 | 2220 | 64.7 | 2959 | 86.3 | 3699 | 107.9 | 4439 | 129.5 | 5770 | 168.3 | |
2.250 | 3.9761 | 13.2782 | 0.3873 | 2213 | 1328 | 38.7 | 1992 | 58.1 | 2656 | 77.5 | 3320 | 96.8 | 3984 | 116.2 | 5179 | 151 | |
2.125 | 3.5466 | 11.8438 | 0.3454 | 2481 | 1185 | 34.5 | 1777 | 51.8 | 2369 | 69.1 | 2961 | 86.4 | 3554 | 103.6 | 4620 | 134.7 | |
2.000 | 3.1416 | 10.4914 | 0.306 | 2801 | 1050 | 30.6 | 1574 | 45.9 | 2099 | 61.2 | 2623 | 76.5 | 3148 | 91.8 | 4092 | 119.3 | |
1.875 | 2.7612 | 9.2209 | 0.2689 | 3187 | 923 | 26.9 | 1384 | 40.3 | 1845 | 53.8 | 2306 | 67.2 | 2767 | 80.7 | 3597 | 104.9 | |
1.750 | 2.4053 | 8.0325 | 0.2343 | 3600 | 804 | 23.4 | 1205 | 35.1 | 1607 | 46.9 | 2009 | 58.6 | 2410 | 70.3 | 3133 | 91.4 | |
217Q-4H (HP200MS) | 1.625 | 2.0739 | 6.926 | 0.202 | 4243 | 693 | 20.2 | 1039 | 30.3 | 1386 | 40.4 | 1732 | 50.5 | 2078 | 60.6 | 2702 | 78.8 |
1.500 | 1.7671 | 5.9014 | 0.1721 | 4980 | 591 | 17.2 | 886 | 25.8 | 1181 | 34.4 | 1476 | 43 | 1771 | 51.6 | 2302 | 67.1 | |
1.375 | 1.4849 | 4.9588 | 0.1446 | 5926 | 496 | 14.5 | 744 | 21.7 | 992 | 28.9 | 1240 | 36.2 | 1488 | 43.4 | 1934 | 56.4 | |
1.250 | 1.2272 | 4.0982 | 0.1195 | 6000 | 410 | 12 | 615 | 17.9 | 820 | 23.9 | 1025 | 29.9 | 1230 | 35.9 | 1599 | 46.6 | |
Brake Horsepower Required | 56 | 84 | 112 | 139 | 167 | 217 |
